P10 Series COB Epistar 40W LED pendant light for Bakery
- FOB Price
US $30.01 - 50 piece
US $29.051 - 100 piece
- group name
- LED pendant lights
- Min Order
- 1 piece
- brand name
- ProFresh
- model
- KPT-PP10AMT-40W-R
- Nearest port for product export
- Shenzhen, HK, Shanghai, Zhejiang
- Delivery clauses under the trade mode
- FOB, CIF, EXW, CIP, DDP, DDU, Express Delivery, DAF, DES
- Acceptable payment methods
- T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow
- Export mode
- Have the independent export and import right
- update time
- Wed, 28 Aug 2024 15:40:54 GMT
Paramtents
led high bay lighting LED source Epistar integrated chip
led high bay lighting CCT Pink color and 2700K-6500K
Material of cover Aluminum
led high bay lighting Voltage AC85-265V
led high bay lighting CRI RA>90
led high bay lighting efficiency 75-90lm/w
led high bay lighting Power 30W,40W
led high bay lighting housing color Red, blue, green, yellow, etc
led high bay lighting brand Profresh LED pendant light
led high bay lighting applicaiton For supermarket lighting
Packging & Delivery
- 42cm x42cm x48cm
-
Min Order1 piece
Briefing
1.CRI: RA90
2.Customized lighting colors for different food environment
3.Epistar integrated chip
Detailed
①Energy saving, use the high power LED as light source, 80% energy saving than incandescent.
②Environmental Protection, no mercury and lead hazardous materials in the light which don’t pollute the environment. Without infrared and ultraviolet to avoid harm to the human body, it’s green lighting products.
③Long lifespan 50,000 hours or more.
④Input voltage is AC85-265V wide range fit for most of customers’ request.
⑤ Use SMD2835 LED chips,High light efficiency，low heat produced, save much electricity.
⑥Constant current driver, no flicker.
⑦Straight ahead light and good directionality, higher light use efficiency than traditional lamps.
⑧The main heat sink is aluminum (DC12) with good thermal conductivity, LEDs touch the red copper plate, so that good heat dissipation
⑨To achieve the desired effect of non-glare lighting surface according to the different food, high color rendering and the food color looks more real. It’s better for customer's to select the food.
led high bay lighting techinical specification:
Rated Power | 40W | ||
Power Consumption | 40±2W | ||
Input Voltage | AC 85~265V/50~60Hz | ||
LED Quantity | integration 1 PCS | ||
LED Chip | Epistar | ||
Light Efficiency | 75-80lm/W | ||
Luminous Flux | 3000~3200LM | ||
Luminaire Efficiency | >85% | ||
Illumination Uniformity | >0.8 | ||
Correlated Color Temperature | 2700K-7000K | ||
Color Rendering Index | Ra≥90 | ||
Beam Angle | 60 º | ||
Grade of Protection | IP40 | ||
Operating Ambient Temperature | -40℃~50℃ | ||
Storage Ambient Temperature | -40℃~50℃（30℃ recommended） | ||
Lamp Operating Temperature | Ambient Temperature | The Radiator Surface of the Lamp Body | LED soldering pot |
25℃ | 55℃ | 63℃ | |
Certification | CE、RoHS | ||
lifespan | 50,000H | ||
Dimensions | See the above specified on the product dimension drawings | ||
N.W. | 1.1kg(with rope) | ||
led high bay lighting Application:
except the vegetable we also have the meat . bread , fish and fruit colors
Meat
Bread
Fish
Fruit
Applications from Customers' Projects
led high bay lighting Packing:
led high bay lighting Installation:
1) Open the box and take out the lamp to check if any scratch. Please contact manufacturer immediately if damaged.
2) Please make sure that the hook is fixed tightly to the lamp.
3) Connect the cable to the electricity and hang the lamp where requested.
led high bay lighting shipping ways:
By air, By Ocean,By International Express(DHL, Fedex,UPS,TNT)
